In Room Measurements
Precise humidity measurements are usually “temperature compensated”, which means that a temperature sensor is needed for accurate measurement. Meanwhile, in the field known as “indoor air quality” the measurement of CO2 plays an important role alongside the precise determination of temperature and humidity.
All-in-One Handheld Device XA1000
The most precise and flexible all-rounder instrument for professional applications-easy to handle and robust for measurement of Temperature/Humidity, flow, co2 and air pressure
The most precise and flexible all-rounder handheld instrument for professional applications detecting temperature, rel. humidity, air pressure, air flow and co2 - easy to handle and robust!
- Integrated sensor for air pressure, exchangable sensors for highly precise measurements of temperature, relative humidity and air flow
- Various - thus exchangable sensors
- Precice and flexible all-rounder handheld instrument, easy to handle and robust, sensor connection with automatic recognition, saves measuring campaignes, allows all climate data to be calculated and archieved, evaluation software SmartGraph3 included
- USB (Cable and SmartGraph3 software included)
Hand-held measuring device XP100
High-precision hand-held device for PT100 temperature sensors.
Very exact temperature measuring device (+/-0.01°C). Ideal as a reference device and for comparison measurements in service or as part of ISO9000 tasks. We recommend a DAkkS calibration certificate for traceability to international standards.
- Temperature / PT100 sensor
- Various - thus exchangable sensors
- Precise and flexible all-rounder handheld instrument, easy to handle and robust, sensor connection with automatic recognition, saves measuring campaignes, allows all climate data to be calculated and archieved, evaluation software SmartGraph3 included
- USB (Cable and SmartGraph3 software included)
Hand-held Measuring Device XP101 for reference temperature
High-precision reference measurement standard for industrial temperature calibrations
The most accurate handheld device (0.005°C) for temperature is an ideal temperature reference in block calibrators, climate chambers or liquid baths.
- Temperature
- PT100 - 4 wire sensing / temperature
- 0.005°C accuracy, high quality wooden case, PT100 ceramic sensor, 2m cable, batteries and DAkks calibration certificate are included in delivery
- USB (Cable and SmartGraph3 software included)
Hand-held measuring device XP200
X-pert range for humidity and temperature measurements in climate and environmental technology.
Measuring device with integrated pressure sensor is compatible with various intelligent temperature and humidity sensors.
- Air pressure, temperature and humidity
- Various - thus exchangable sensors
- Precice and flexible all-rounder handheld instrument, easy to handle and robust, sensor connection with automatic recognition, saves measuring campaignes, allows all climate data to be calculated and archieved, evaluation software SmartGraph3 included
- USB (Cable and SmartGraph3 software included)
Hand-held measuring device XP201 for reference humidity
High-precision reference measurement standard for industrial humidity calibrations
The most accurate handheld device (0.5%) for relative humidity. Ideal as reference standard. Excellent stability, very good repeatable measurements, absolute hysteresis latitude as well as no drift of the measurement value at very high humidity levels. For traceability to national standards a DAkkS calibration certificate is attached.
- Relative humidity, temperature and air pressure
- resistive-electrolytic / Humidity
- High-precision measurement of temperature and relative humidity (0.5 % accuracy), display of calculations and statistical functions, high-quality case, resistive-electrolytic humidity sensor, 2m cable, batteries and DAkks calibration certificate included in delivery
- USB (Cable and SmartGraph3 software included)
Hand-held measuring device XP400
Ideal for volume measurements, air intake and air discharge measurements in climate measuring technology. Data memory and software.
The X-pert for precise airflow measurements on various measurement ranges.
- The X-pert for precise airflow measurements on various measurement ranges.
- Various - thus exchangable sensors
- Precice and flexible all-rounder handheld instrument, easy to handle and robust, sensor connection with automatic recognition, saves measuring campaignes, allows all climate data to be calculated and archieved, evaluation software SmartGraph3 included
- USB (Cable and SmartGraph3 software included)
Hand-held measuring device XC200
High-precision reference measurement standard for industrial temperature calibrations
Excellent accuracy of temperature and relative humidity. Display of calculations and statistical functions. Adjustment of local pressure and local height possible. Calibration function and offset correction. Including a calibration certificate. USB interface with SmartGraph3 software.
- Relative humidity, Temperature
- Temperature / NTC (Negative Temperature Coefficient); Rel. humidity / Capacitive
- Excellent accuracy of temperature and relative humidity. Display of calculations and statistical functions.
- USB (Cable and SmartGraph3 software included)
Hand-held measuring device XC250 (with pyrometer)
High-precision reference measurement standard for industrial temperature calibrations
Excellent accuracy of temperature and relative humidity. Display of calculations and statistical functions. Adjustment of local pressure and local height possible. Calibration function and offset correction. Including a calibration certificate. USB interface with SmartGraph3 software.
- Relative humidity, Temperature, Surface temperature
- Temperature / NTC (Negative Temperature Coefficient); Rel. humidity / Capacitive; Surface Temp. / Pyrometer (thermopile)
- Excellent accuracy of temperature and relative humidity. Display of calculations and statistical functions.
- USB (Cable and SmartGraph3 software included)
Lufft I-BOX serial - Gateway for Measuring Technology
We proudly present you the Lufft I-BOX Serial, the door opener for almost every interface – thanks to app-technology!
With the Lufft I-Box Serial, weather sensors such as the WSxxx product family can easily be integrated into existing systems. The “plug-and-play” solution gives a uniform query to live data from different instruments.
- Data processing device - no measurements available without connected sensors
- Data processing device - no measurement technology available
- Easy commissioning (Plug & Play), Configuration and remote maintenance via browser interface, Applications upgradeable as required, Increased interference immunity for the industrial environment, Transmission of measured values to the corporate network
- LAN, Serial combi - interface with RS232/422/485
OPUS 20 THI
For climate monitoring in buildings and the control of all climate-sensitive production processes
For climate monitoring in buildings and the control of all climate-sensitive production processes: in electronic data-processing centres, control cabinets, wind turbines, storage rooms and museums
- Temperature & Relative humidity
- Temperature / NTC, Humidity / Capacitive
- LAN datalogger with built-in sensors and highest precision, evaluation software SmartGraph3 included
- USB (Cable and SmartGraph3 monitoring software included)
OPUS 20 THIP
Lufft OPUS20 - An essential data collector for all calibration laboratories measuring precise temperature, relative humidity and air pressure!
Lufft OPUS20 - An essential data collector for all calibration laboratories measuring precise temperature, relative humidity and air pressure!
- Temperature, relative humidity and air pressure
- Temperature & air pressure / NTC, Humidity / Capacitive
- LAN datalogger with built-in sensors and highest precision, evaluation software SmartGraph3 included
- USB (Cable and SmartGraph3 monitoring software included)
OPUS 20 TCO
Inroom Data Logger for measurement of temperature, humidity, air pressure and CO2 (Indoor Air Quality), made in Germany!
Inroom Data Logger for measurement of temperature, relative humidity and CO2 (Indoor Air Quality), made in Germany!
- Temperature, Relative humidity, CO2
- Temperature / NTC, Humidity / Capacitive, CO2 / NDIR
- LAN datalogger with built-in sensors and the highest precision! Firmware online updatable
- USB (Cable and Monitoring Software SmartGraph3 included)
OPUS 20E for external Sensors
The OPUS20E offers the highest flexibility and is excellent value for money. It allows the connection of up to 4 external temperature and relative humidity sensors, as well as 2 further analogue sensors. Intelligent BUS sensors can be integrated...
The OPUS20E offers the highest flexibility and is excellent value for money. It allows the connection of up to 4 external temperature and relative humidity sensors, as well as 2 further analogue sensors. Intelligent BUS sensors can be integrated via the OP
- Measurement of Input voltage 0-1V, Current measurement - 2-wires, Current measurement - 3-wires, Thermocouple K, Thermocouple J, Thermocouple S, PT100
- Input voltage 0-1V, Current measurement - 2-wires, Current measurement - 3-wires, Thermocouple K, Thermocouple J, Thermocouple S, PT100
- LAN datalogger with built-in sensors and the highest precision and with up to 10 external channels/sensors per Opus20E.
- USB (Cable and Monitoring Software SmartGraph3 included)
